AC / DC Split Core Hall Current Sensor Plate Type Mounting CE Approved CS200EK1

Name: AC DC Split Core Hall Current Sensor Plate Type Mounting CE Approved CS200EK1
Brand: chieful
Price: 1 USD

Place of Origin : Jiangsu, China (Mainland)

Brand Name : chieful

Model Number : CS200EK1

MOQ : 1-499 Pieces

Price : Negotiable

Usage : Magnetic Sensor

Theory : Hall Sensor

Output : Analog Sensor

diameter : 21mm

weight : 66g

Application : Automation

Product name : split core current transducer CS200EK1

Type : open loop

Certificate : CE ,RoHS,ISO9001

Capacity : 100000pcs/month

Warranty : 5 years

Selling Units : Single item

Single package size : 23X18X7 cm

Single gross weight : 0.066 kg

Package Type : packing in the bubble

Contact Now

AC / DC Split Core Hall Current Sensor Plate Type Mounting CE Approved CS200EK1

Product Description

This Hall effect current sensor can be used for measurement of DC and AC current, pulsed currents etc. The output of the transducer reflects the real wave of the current carrying conductor.

Characteristic:

Open loop split core type, plate type mounting,
DC,AC and pulse current detecting.
Fire resistance property: in accordance with UL94-Vo
Work temperature:-40°C~+85°C
Storage temperature:-55°C~+125°C
Work frequency:DC25KHz
Dielectric strength:2.5KV(RMS)

split core current transducer CS200EK1

Electrical characteristics
	Type	CS050EK1	CS100EK1	CS200EK1	CS300EK1	CS400EK1	CS500EK1
I_PN	Primary nominal input current	50	100	200	300	400	500	A
I_P	Measuring range of primary current	0~±100	0~±200	0~±400	0~±600	0~±800	0~±1000	A
V_OUT	Nominal output voltage	4±1%						V
V_C	Supply voltage	±12~±15(±5%)						V
I_C	Current consumption	V_C=±15V <25						mA
V_D	Insulation voltage	AC/50Hz/1min 3						kV
ε_L	Linearity	<1						%FS
V_O	Offset voltage	T_A=25℃ <±25						mV
V_OM	Residual voltage	I_PN→0 <±25						mV
V_OT	Thermal drift of V₀	I_P=0 T_A=–25~+85℃ <±1						mV/℃
T_R	Response time	≤7						μs
f	Frequency bandwidth(-3dB)	DC~20						kHz
T_A	Ambient operating temperature	–25~+85						℃
T_S	Ambient storage temperature	–40~+100						℃
R_L	Load resistance	≥10						KΩ
	Standard	Q/3201CHGL02-2016
