35mm Hole Diameter Hall Effect Linear Current Sensor For Welding Machine

Name: 35mm Hole Diameter Hall Effect Linear Current Sensor For Welding Machine
Brand: chieful
Price: 1 USD

Place of Origin : Jiangsu, China (Mainland)

Brand Name : chieful

Model Number : CS800EKH

MOQ : 1 Piece

Price : Negotiable

Usage : Magnetic Sensor

Theory : Hall Sensor

Output : Analog Sensor

color : blue

weight : 80g

Diameter : 35mm

Selling Units : Single item

Single package size : 20X17X8 cm

Single gross weight : 0.08 kg

Package Type : packing in bubble

Contact Now

35mm Hole Diameter Hall Effect Linear Current Sensor For Welding Machine

This Hall effect current sensor can be used for measurement of DC and AC current, pulsed currents etc. The output of the transducer reflects the real wave of the current carrying conductor.

Hall effect linear current sensor CS800EKH

Electrical characteristics
	Type	CS100EKH	CS200EKH	CS300EKH	CS500EKH	CS800EKH
I_PN	Primary nominal input current	100	200	300	500	800	A
I_P	Measuring range of primary current	0~±200	0~±400	0~±600	0~±1000	0~±1200	A
V_OUT	Nominal output voltage	4±1%					V
V_C	Supply voltage	±15(±5%)					V
I_C	Current consumption	V_C=±15V <20					mA
V_D	Insulation voltage	AC/50Hz/1min 2.5					kV
ε_L	Linearity	<1					%FS
V_O	Offset voltage	T_A=25℃ <±25					mV
V_OM	Residual voltage	I_PN→0 <±20					mV
V_OT	Thermal drift of V₀	I_P=0 T_A=–25~+85℃ <±1					mV/℃
T_R	Response time	≤3					μs
f	Frequency bandwidth(-3dB)	DC~20					kHz
T_A	Ambient operating temperature	–25~+85					℃
T_S	Ambient storage temperature	–40~+100					℃
R_L	Load resistance	≥10					KΩ
	Standard	Q/320115QHKJ01-2010

35mm Hole Diameter Hall Effect Linear Current Sensor For Welding Machine

About us

CHIEFUL offers a wide range of current and voltage transducers in the portfolio. And our transducer can be designed according to the specific demands.The company explore foreign markets actively, our products have been sold to the United Kingdom, Germany, Denmark, France, Italy, Sweden,Turkey, Israel, South Korea, India etc.

FAQ

Q1: Are you a factory?
A:We are a factory setted up more than 17 years and export more than 10years.

Q2: When is the delivery date?
A: 7-10 working days in general.

Q3: Could you send me a quotation?
A: Sure.

Q4: How about the after service?
A: Five years warranty.

Q5: What about the shipping package?
A: Anti-static package and carton.
